| 1 | 20S-17411-00-00 | Axle, Main (13T) | 1 шт. | — | |
|
| 2 | 90387-253M6-00 | Collar | 1 шт. | — | |
|
| 3 | 20S-17151-00-00 | Gear, 5Th Pinion (21T) | 1 шт. | — | |
|
| 4 | 90209-21332-00 | Washer | 2 шт. | — | |
|
| 5 | 93440-25186-00 | Circlip | 2 шт. | — | |
|
| 6 | 20S-17131-10-00 | Gear, 3Rd Pinion (18T/24T) | 1 шт. | — | |
|
| 7 | 90387-2513E-00 | Collar | 1 шт. | — | |
|
| 8 | 20S-17161-10-00 | Gear, 6Th Pinion (24T) | 1 шт. | — | |
|
| 9 | 90209-22352-00 | Washer | 1 шт. | — | |
|
| 10 | 90209-21351-00 | Washer | 1 шт. | — | |
|
| 11 | 20S-17121-10-00 | Gear, 2Nd Pinion (19T) | 1 шт. | — | |
|
| 12 | 20S-15163-00-00 | Housing, Bearing 1 | 1 шт. | — | |
|
| 13 | 93306-30525-00 | Bearing | 1 шт. | — | |
|
| 14 | 93306-20483-00 | Bearing | 1 шт. | — | |
|
| 15 | 90151-06024-00 | Screw, Countersunk | 3 шт. | — | |
|
| 16 | 20S-17421-01-00 | Axle, Drive | 1 шт. | — | |
|
| 17 | 93306-30550-00 | Bearing | 1 шт. | — | |
|
| 18 | 90387-2504A-00 | Collar | 1 шт. | — | |
|
| 19 | 90387-2813C-00 | Collar | 1 шт. | — | |
|
| 20 | 20S-17221-00-00 | Gear, 2Nd Wheel (37T) | 1 шт. | — | |
|
| 21 | 90209-25342-00 | Washer | 3 шт. | — | |
|
| 22 | 93440-28062-00 | Circlip | 3 шт. | — | |
|
| 23 | 20S-17261-10-00 | Gear, 6Th Wheel (26T) | 1 шт. | — | |
|
| 24 | 90387-2813D-00 | Collar | 2 шт. | — | |
|
| 25 | 20S-17241-00-00 | Gear, 4Th Wheel (32T) | 1 шт. | — | |
|
| 26 | 90209-25349-00 | Washer | 1 шт. | — | |
|
| 27 | 90209-25350-00 | Washer | 1 шт. | — | |
|
| 28 | 20S-17231-00-00 | Gear, 3Rd Wheel (28T) | 1 шт. | — | |
|
| 29 | 20S-17251-00-00 | Gear, 5Th Wheel (25T) | 1 шт. | — | |
|
| 30 | 90387-2202V-00 | Collar | 1 шт. | — | |
|
| 31 | 20S-17211-00-00 | Gear, 1St Wheel (37T) | 1 шт. | — | |
|
| 32 | 93102-35423-00 | Oil Seal | 1 шт. | — | |
|
| 33 | 20S-17460-00-00 | Sprocket, Drive (16T) | 1 шт. | — | |
|
| 34 | 90201-20023-00 | Washer, Plate | 1 шт. | — | |
|
| 35 | 90179-20011-00 | Nut | 1 шт. | — | |
|
| 36 | 90201-20278-00 | Washer, Plate | 1 шт. | — | |
|
| 37 | 93306-20483-00 | Bearing | 1 шт. | — | |
|
| 38 | 278-17424-01-00 | Circlip 1 | 1 шт. | — | |
|
