| 1 | 94A40-02114-00 | Set, Chain (Did525v11-114) | 1 шт. | — | |
|
| 2 | 94682-4703R-00 | . .Joint, Chain (Did525v11 Zj) | 1 шт. | — | |
|
| 3 | BN6-25338-00-P0 | Cast Wheel, Rear UR FOR DPBMC | 0 шт. | — | |
|
| 4 | BN6-25338-00-98 | Cast Wheel, Rear UR FOR MDNM6 | 1 шт. | — | |
|
| 5 | BN6-25338-00-P1 | Cast Wheel, Rear UR FOR BWP1 | 0 шт. | — | |
|
| 6 | 93306-20531-00 | Bearing | 1 шт. | — | |
|
| 7 | BN6-2538E-00-00 | Nut, Adjusting | 1 шт. | — | |
|
| 8 | 93106-40001-00 | Oil Seal | 1 шт. | — | |
|
| 9 | 93317-43580-00 | Bearing | 1 шт. | — | |
|
| 10 | 5PW-25317-00-00 | Spacer, Bearing | 1 шт. | — | |
|
| 11 | 2PW-2517G-00-00 | Rotor, Sensor | 1 шт. | — | |
|
| 12 | 90149-05029-00 | Screw | 5 шт. | — | |
|
| 13 | 5SL-25383-00-00 | Collar, Wheel | 1 шт. | — | |
|
| 14 | 2C0-25364-00-00 | Damper | 6 шт. | — | |
|
| 15 | 5SL-25366-00-00 | Clutch, Hub | 1 шт. | — | |
|
| 16 | 93306-20531-00 | Bearing | 1 шт. | — | |
|
| 17 | 93106-40013-00 | Oil Seal | 1 шт. | — | |
|
| 18 | 2C0-25445-20-00 | Sprocket, Driven (45T) | 1 шт. | — | |
|
| 19 | 90116-10048-00 | Bolt, Stud | 6 шт. | — | |
|
| 20 | 90185-10011-00 | Nut, Self-Locking | 6 шт. | — | |
|
| 21 | 93900-00030-00 | Valve, Rim (Tr412) TAIHEIYO | 1 шт. | — | |
|
| 22 | 94118-17081-00 | Tire(180/55 Zr17 M/C 73W) UR BRIDGESTONE | 1 шт. | — | |
|
| 23 | 94118-17082-00 | Tire(180/55 Zr17 M/C 73W) UR DUNLOP | 1 шт. | — | |
|
| 24 | 5MT-25398-00-00 | Balancer, Wheel (10G) UN | 1 шт. | — | |
|
| 25 | 5MT-25398-10-00 | Balancer, Wheel (20G) UN | 1 шт. | — | |
|
| 26 | 5MT-25398-20-00 | Balancer, Wheel (30G) UN | 1 шт. | — | |
|
| 27 | 13S-25376-00-00 | Collar, Wheel | 1 шт. | — | |
|
| 28 | 90387-28016-00 | Collar | 1 шт. | — | |
|
| 29 | 4XV-25381-10-00 | Axle, Wheel | 1 шт. | — | |
|
| 30 | 90185-24008-00 | Nut, Self-Locking | 1 шт. | — | |
|
| 31 | 90201-25020-00 | Washer, Plate | 1 шт. | — | |
|
| 32 | 4XV-25388-00-00 | Puller, Chain 1 | 1 шт. | — | |
|
| 33 | 4XV-25389-00-00 | Puller, Chain 2 | 1 шт. | — | |
|
