| 1 | 2KS-Y283G-50-1X | Body, Front Upper 1 BWM2 | 1 шт. | — | |
|
| 2 | 2CR-28381-10-00 | . .Windshield | 1 шт. | — | |
|
| 3 | 2CR-2832P-00-00 | . Graphic, 18 | 1 шт. | — | |
|
| 4 | 90179-05523-00 | . Nut | 4 шт. | — | |
|
| 5 | 2CR-28333-00-00 | . Bolt | 4 шт. | — | |
|
| 6 | 90202-05088-00 | . Washer, Plate | 4 шт. | — | |
|
| 8 | 99246-00100-00 | . .Emblem, Yamaha | 2 шт. | — | |
|
| 9 | 2KS-2834X-00-00 | . .Graphic Set 1, Cowling | 1 шт. | — | |
|
| 10 | 4B5-2815K-00-00 | . Label, Notice Windshield 1 | 1 шт. | — | |
|
| 11 | 90111-05045-00 | Bolt,Hex. Socket Button | 2 шт. | — | |
|
| 12 | 2CR-2835H-00-00 | Body, Front Upper 2 | 1 шт. | — | |
|
| 13 | 90480-10003-00 | Grommet | 2 шт. | — | |
|
| 14 | 90164-05001-00 | Screw, Tapping | 4 шт. | — | |
|
| 15 | 2C0-28247-00-00 | Damper 4 | 4 шт. | — | |
|
| 16 | 2CR-84301-00-00 | Pilot Light Assy 1 | 1 шт. | — | |
|
| 19 | 2CR-84302-00-00 | Pilot Light Assy 2 | 1 шт. | — | |
|
| 20 | 97702-50014-00 | Screw, Tapping | 3 шт. | — | |
|
| 20 | 97702-50014-00 | Screw, Tapping | 3 шт. | — | |
|
| 21 | 90183-05076-00 | . Nut, Spring | 2 шт. | — | |
|
| 21 | 90183-05076-00 | Nut, Spring | 1 шт. | — | |
|
| 21 | 90183-05076-00 | Nut, Spring | 1 шт. | — | |
|
| 22 | 90464-25160-00 | Clamp | 1 шт. | — | |
|
| 23 | 2CR-28320-00-00 | Leg Shield Stay Set | 1 шт. | — | |
|
| 24 | 2CR-28356-00-00 | . .Stay 1 | 1 шт. | — | |
|
| 25 | 90183-060A1-00 | . Nut, Spring | 2 шт. | — | |
|
| 26 | 4XV-83513-00-00 | . Damper | 7 шт. | — | |
|
| 27 | 4C8-26298-00-00 | . Plate, Mirror Fitting 1 | 2 шт. | — | |
|
| 28 | 2CR-22873-00-00 | . Seal 1 | 2 шт. | — | |
|
| 29 | 2CR-284AK-00-00 | . .Collar ,4 | 4 шт. | — | |
|
| 30 | 90445-086J3-00 | Hose (L320) | 1 шт. | — | |
|
| 31 | 5PS-14568-00-00 | Joint | 1 шт. | — | |
|
| 32 | 90111-06038-00 | Bolt,Hex. Socket Button | 4 шт. | — | |
|
| 33 | 90111-06071-00 | Bolt,Hex. Socket Button | 4 шт. | — | |
|
| 34 | 2CR-26280-10-00 | Rear View Mirror Assy (Left) | 1 шт. | — | |
|
| 36 | 2CR-26290-10-00 | Rear View Mirror Assy (Right) | 0 шт. | — | |
|
| 37 | 90176-06055-00 | Nut, Crown | 2 шт. | — | |
|
| 37 | 90176-06055-00 | Nut, Crown | 2 шт. | — | |
|
| 38 | 2CR-2836J-00-00 | Bracket 6 | 1 шт. | — | |
|
| 41 | 2KS-28468-00-00 | Brkt. 7 | 1 шт. | — | |
|
| 42 | 90387-06184-00 | Collar | 2 шт. | — | |
|
| 42 | 90387-06184-00 | Collar | 1 шт. | — | |
|
| 43 | 92012-06014-00 | Bolt, Button Head | 1 шт. | — | |
|
| 43 | 92012-06014-00 | Bolt, Button Head | 2 шт. | — | |
|
| 44 | 8GE-21852-00-00 | Damper | 2 шт. | — | |
|
