| 1 | 90110-06168-00 | Bolt, Hexagon Socket Head | 6 шт. | — | |
|
| 2 | 2CR-13635-00-00 | Joint, Intake 1 | 1 шт. | — | |
|
| 3 | 90450-60004-00 | Hose Clamp Assy | 2 шт. | — | |
|
| 4 | 2CR-13636-00-00 | Joint, Intake 2 | 1 шт. | — | |
|
| 5 | 90450-60004-00 | Hose Clamp Assy | 2 шт. | — | |
|
| 6 | 2CR-14411-00-00 | Case, Air Cleaner 1 | 1 шт. | — | |
|
| 7 | 2CR-14457-00-00 | . .Seal | 2 шт. | — | |
|
| 8 | 2CR-14462-00-00 | . .Seal | 1 шт. | — | |
|
| 9 | 2CR-14425-00-00 | . .Damper 1 | 1 шт. | — | |
|
| 10 | 14B-85870-00-00 | Geared Motor Comp. 2 | 0 шт. | — | |
|
| 11 | 2CR-14490-00-00 | Shaft Assy | 1 шт. | — | |
|
| 12 | 90110-05047-00 | Bolt, Hexagon Socket Head | 3 шт. | — | |
|
| 13 | 2CR-15393-00-00 | Pipe, Breather 2 | 1 шт. | — | |
|
| 14 | 90467-15001-00 | Clip | 1 шт. | — | |
|
| 15 | 2CR-1440B-00-00 | Joint Assy | 1 шт. | — | |
|
| 16 | 90480-12010-00 | Grommet | 1 шт. | — | |
|
| 17 | 2CR-14498-00-00 | Stay 1 | 1 шт. | — | |
|
| 18 | 8FP-13556-00-00 | .Rubber, Injector | 4 шт. | — | |
|
| 19 | 2CR-1393A-00-00 | .Pipe, Inlet | 1 шт. | — | |
|
| 20 | 2CR-1393B-00-00 | .Pipe, Inlet 2 | 1 шт. | — | |
|
| 21 | 2CR-1440F-00-00 | Joint, Air Filter 1 | 1 шт. | — | |
|
| 22 | 5UX-14118-00-00 | . .Cap | 1 шт. | — | |
|
| 23 | 39P-14147-00-00 | . ..O-Ring | 2 шт. | — | |
|
| 24 | 363-14198-00-00 | .Gasket | 4 шт. | — | |
|
| 25 | 14B-13573-00-00 | .Bolt 1 | 4 шт. | — | |
|
| 26 | 2CR-14421-00-00 | Case, Air Cleaner 2 | 1 шт. | — | |
|
| 27 | 2CR-14452-00-00 | . .Seal | 1 шт. | — | |
|
| 28 | 14B-13761-10-00 | Injector | 4 шт. | — | |
|
| 29 | 5PS-14147-00-00 | . ..O-Ring | 1 шт. | — | |
|
| 30 | 2CR-14451-00-00 | Element, Air Cleaner | 1 шт. | — | |
|
| 31 | 2CR-13972-00-00 | Pipe, Fuel 2 | 1 шт. | — | |
|
| 32 | 98907-05020-00 | Screw, Bind | 10 шт. | — | |
|
| 33 | 90467-160A6-00 | Clip | 1 шт. | — | |
|
| 34 | 2CR-12682-00-00 | Protector, Heat | 1 шт. | — | |
|
| 35 | 14B-21684-00-00 | Plate, Routing FOR CALIFORNIA | 0 шт. | — | |
|
| 36 | 2CR-21686-00-00 | Plate, Routing 2 FOR CALIFORNIA | 0 шт. | — | |
|
