| 1 | 1WD-H2310-00-00 | Ignition Coil Assy | 2 шт. | — | |
|
| 2 | B04-H2314-00-00 | Cover, Ignition Coil | 1 шт. | — | |
|
| 3 | B04-H2314-10-00 | Cover, Ignition Coil | 1 шт. | — | |
|
| 4 | 95022-06020-00 | Bolt, Flange | 2 шт. | — | |
|
| 5 | 1WD-H2370-00-00 | Plug Cap Assy | 2 шт. | — | |
|
| 6 | 1WD-H2100-00-00 | Battery Assy (Gs Gtz8v) | 1 шт. | — | |
|
| 7 | 1WD-H2121-00-00 | Pad, Battery | 1 шт. | — | |
|
| 8 | 1WD-H2131-00-00 | Band, Battery | 1 шт. | — | |
|
| 9 | 2MS-H2590-00-00 | Wire Harness Assy | 1 шт. | — | |
|
| 10 | 1WD-H2151-20-00 | . .Fuse (7.5A Bl) | 0 шт. | — | |
|
| 11 | 1WD-H2151-10-00 | . .Fuse (15A-Bl) | 4 шт. | — | |
|
| 12 | 4WA-81980-00-00 | . .Diode Assy | 1 шт. | — | |
|
| 13 | 3WP-81980-00-00 | . .Diode Assy | 2 шт. | — | |
|
| 14 | 1WD-H1950-00-00 | Relay Assy | 3 шт. | — | |
|
| 15 | 1WD-H1940-00-00 | Starter Relay Assy | 1 шт. | — | |
|
| 16 | 1WD-H2151-00-00 | . .Fuse (30A-Bl) | 2 шт. | — | |
|
| 17 | 91312-05008-00 | Bolt, Hexagon Socket Head | 2 шт. | — | |
|
| 18 | 1WD-H2115-00-00 | Wire, Plus Lead | 1 шт. | — | |
|
| 19 | 1WD-H2116-01-00 | Wire, Minus Lead | 1 шт. | — | |
|
| 20 | 90464-36800-00 | Clamp | 2 шт. | — | |
|
| 21 | 90464-70800-00 | Clamp | 7 шт. | — | |
|
| 22 | 90464-14803-00 | Clamp | 1 шт. | — | |
|
| 23 | 90464-22800-00 | Clamp | 1 шт. | — | |
|
| 24 | 1WD-H2501-02-00 | Main Switch Steering Lock | 1 шт. | — | |
|
| 25 | 1WD-H2511-09-00 | Blank Key AP | 1 шт. | — | |
|
| 26 | 90109-060G4-00 | Bolt | 2 шт. | — | |
|
| 27 | 1WD-H2566-00-00 | Switch, Side Stand | 1 шт. | — | |
|
| 28 | 90110-05809-00 | Bolt, Hexagon Socket Head | 0 шт. | — | |
|
| 29 | 1WD-XH250-02-00 | Main Switch Steering Lock Sub A AP | 1 шт. | — | |
|
| 30 | 1WD-F179E-00-00 | Band | 1 шт. | — | |
|
| 31 | 1WD-H2591-00-00 | Band | 1 шт. | — | |
|
| 32 | 90464-26001-00 | Clamp | 1 шт. | — | |
|
| 33 | 90464-13227-00 | Clamp | 1 шт. | — | |
|
