| 1 | 1WD-F3100-00-00 | Front Fork Assy | 1 шт. | — | |
|
| 2 | 1WD-F3102-00-00 | . .Front Fork Assy (L.H) | 1 шт. | — | |
|
| 3 | 1WD-F3126-00-00 | . . ..Tube, Outer (L.H) | 1 шт. | — | |
|
| 4 | 1WD-F3110-00-00 | . . Inner Tube Comp. 1 | 1 шт. | — | |
|
| 5 | 1WD-F3170-00-00 | . . ..Cylinder Comp., Front For | 1 шт. | — | |
|
| 6 | 1WD-F3141-00-00 | . . ..Spring, Front Fork | 1 шт. | — | |
|
| 7 | 45P-F3125-00-00 | . . ..Metal, Slide 1 | 1 шт. | — | |
|
| 8 | 45P-F3146-00-00 | . . ..Washer, Oil Seal | 1 шт. | — | |
|
| 9 | 45P-F3145-00-00 | . . Oil Seal INCL. IN FORK SEAL KIT | 1 шт. | — | |
|
| 10 | 45P-F3156-00-00 | . . ..Ring, Snap | 1 шт. | — | |
|
| 11 | 45P-F3144-00-00 | . . Seal, Dust INCL. IN FORK SEAL KIT | 1 шт. | — | |
|
| 12 | 1WD-F3173-00-00 | . . ..Spindle, Taper | 1 шт. | — | |
|
| 13 | 509-F3158-L0-00 | . . ..Gasket | 1 шт. | — | |
|
| 14 | 31B-F3181-00-00 | . . ..Bolt, Hexagon Socket Head | 1 шт. | — | |
|
| 15 | 45P-F3149-00-00 | . . ..Washer, Spring Upper | 1 шт. | — | |
|
| 16 | 1WD-F3118-00-00 | . . ..Spacer | 0 шт. | — | |
|
| 17 | 45P-F3111-00-00 | . . ..Bolt, Cap | 0 шт. | — | |
|
| 18 | 45P-F3188-00-00 | . . ..O-Ring | 1 шт. | — | |
|
| 19 | 1WD-F3103-00-00 | . .Front Fork Assy (R.H) | 1 шт. | — | |
|
| 20 | 1WD-F3136-00-00 | . . ..Tube, Outer 2 | 1 шт. | — | |
|
| 21 | 1WD-F3110-00-00 | . . Inner Tube Comp. 1 | 1 шт. | — | |
|
| 22 | 1WD-F3170-00-00 | . . ..Cylinder Comp., Front For | 1 шт. | — | |
|
| 23 | 1WD-F3141-00-00 | . . ..Spring, Front Fork | 1 шт. | — | |
|
| 24 | 45P-F3125-00-00 | . . ..Metal, Slide 1 | 1 шт. | — | |
|
| 25 | 45P-F3146-00-00 | . . ..Washer, Oil Seal | 1 шт. | — | |
|
| 26 | 45P-F3145-00-00 | . . Oil Seal INCL. IN FORK SEAL KIT | 1 шт. | — | |
|
| 27 | 45P-F3156-00-00 | . . ..Ring, Snap | 1 шт. | — | |
|
| 28 | 45P-F3144-00-00 | . . Seal, Dust INCL. IN FORK SEAL KIT | 1 шт. | — | |
|
| 29 | 1WD-F3173-00-00 | . . ..Spindle, Taper | 1 шт. | — | |
|
| 30 | 509-F3158-L0-00 | . . ..Gasket | 1 шт. | — | |
|
| 31 | 31B-F3181-00-00 | . . ..Bolt, Hexagon Socket Head | 1 шт. | — | |
|
| 32 | 45P-F3149-00-00 | . . ..Washer, Spring Upper | 1 шт. | — | |
|
| 33 | 1WD-F3118-00-00 | . . ..Spacer | 0 шт. | — | |
|
| 34 | 45P-F3111-00-00 | . . ..Bolt, Cap | 0 шт. | — | |
|
| 35 | 45P-F3188-00-00 | . . ..O-Ring | 1 шт. | — | |
|
| 36 | 1WD-F3340-00-00 | . .Under Bracket Comp | 1 шт. | — | |
|
| 37 | 93399-99932-00 | . . Bearing | 1 шт. | — | |
|
| 38 | 3FV-23462-00-00 | . . Seal, Steering | 1 шт. | — | |
|
| 39 | 45P-F3346-00-00 | . .Bolt 1 | 2 шт. | — | |
|
| 40 | 1WS-2331G-00-00 | . Cover | 2 шт. | — | |
|
| 41 | 2MS-W003B-00-00 | Fork Seal Kit NOT SHOWN | 1 шт. | — | |
|
