Fuel Tank Cover (Gsx-R750z)

Схема Fuel Tank Cover (Gsx-R750z)

№	Артикул	Название	Кол-во	Наличие и цены	Действия

1	`11401-02892`	GASKET SET OPT	1 шт.	—

2	`11141-02H00`	.GASKET,CYLINDER HEAD NOT ILLUSTRATED	1 шт.	—

3	`11173-01H00`	.GASKET,CYL HEAD COVER NO.1 NOT ILLUSTRATED	1 шт.	—

4	`11178-01H00`	.GASKET,CYL HEAD COVER NO.2 NOT ILLUSTRATED	2 шт.	—

5	`11191-27E00`	WASHER,CYL HEAD COVER (L:5.5) NOT ILLUSTRATED	6 шт.	—

6	`11482-01H00`	.GASKET,CLUTCH COVER NOT ILLUSTRATED	1 шт.	—

7	`11483-01H00`	.GASKET,GENERATOR COVER NOT ILLUSTRATED	1 шт.	—

8	`11484-01H00`	.GASKET,BREATHER COVER NOT ILLUSTRATED	1 шт.	—

9	`11489-01H01`	.GASKET,OIL PAN NOT ILLUSTRATED	1 шт.	—

10	`12837-02H00`	.GASKET,TENSIONER ADJUSTER NOT ILLUSTRATED	1 шт.	—

11	`14181-46E10`	.GASKET,EXHAUST NOT ILLUSTRATED	4 шт.	—

12	`09280-15007`	O RING (D:2.4,ID:15.8) NOT ILLUSTRATED	1 шт.	—

13	`09280-17003`	O-RING (D:3.1,ID:16.8) NOT ILLUSTRATED	1 шт.	—

14	`09280-25004`	O RING (D:2.4,ID:24.7) NOT ILLUSTRATED	1 шт.	—

15	`09280-33004`	O-RING (D:3.1,ID:32.7) NOT ILLUSTRATED	1 шт.	—

16	`09280-71008`	.O-RING (D:2.6 ID:67.1) NOT ILLUSTRATED	1 шт.	—

17	`15201-35F00`	O RING,FUEL PUMP NOT ILLUSTRATED	1 шт.	—
