| 1 | 64111-14J00-019 | WHEEL,REAR (17M/CXMT5.50,BLAC ) | 1 шт. | — | |
|
| 2 | 64731-14J00 | SPACER,REAR WHEEL BEARING | 1 шт. | — | |
|
| 3 | 08123-6205B | BEARING | 1 шт. | — | |
|
| 4 | 08123-6005B | BEARING | 1 шт. | — | |
|
| 5 | 09285-32004 | .SEAL,OIL (32X52X7) | 1 шт. | — | |
|
| 6 | 69211-18G00 | DISC,REAR BRAKE | 1 шт. | — | |
|
| 7 | 09106-08160 | BOLT (8X21) | 5 шт. | — | |
|
| 8 | 64711-14J00 | AXLE,REAR | 1 шт. | — | |
|
| 9 | 64721-13K00 | NUT | 1 шт. | — | |
|
| 10 | 09160-22081 | WASHER (22X35X2) | 1 шт. | — | |
|
| 11 | 54751-41G10 | SPACER,FR AXLE,R | 1 шт. | — | |
|
| 12 | 64751-44G00 | SPACER,RR AXLE,L | 1 шт. | — | |
|
| 13 | 64610-47H00 | DRUM,RR SPROCKET | 1 шт. | — | |
|
| 14 | 64733-44G00 | RETAINER,RR SPROCKET DRUM | 1 шт. | — | |
|
| 15 | 09262-32024 | BEARING (32X65X17) | 1 шт. | — | |
|
| 16 | 09285-39001 | OIL SEAL (39X65X7) | 1 шт. | — | |
|
| 17 | 64651-47H10 | ABSORBER,RR HUB SHOCK | 6 шт. | — | |
|
| 18 | 64511-15J00 | SPROCKET,RR (45T-525) | 1 шт. | — | |
|
| 19 | 08319-3110A | NUT | 6 шт. | — | |
|
| 20 | 65110-15J00 | TIRE,REAR (180/55ZR17M/C, 73W | 1 шт. | — | |
|
| 21 | 43130-24A00 | VALVE ASSY,WHEEL RIM (TR412) | 1 шт. | — | |
|
| 22 | 55411-22H00 | BALANCER,WHEEL (10G) | 1 шт. | — | |
|
| 23 | 55412-22H00 | BALANCER,WHEEL (20G) | 1 шт. | — | |
|
| 24 | 55413-22H00 | BALANCER,WHEEL (30G) | 1 шт. | — | |
|
| 25 | 68251-14J10-B86 | TAPE,WHEEL (ORANGE,BLACK) | 2 шт. | — | |
|
| 26 | 68251-14J10-GY8 | TAPE,WHEEL (YELLOW/BLACK) | 2 шт. | — | |
|
