| 1 | 64110-41F20 | HUB,REAR | 0 шт. | — | |
|
| 2 | 65311-41F00 | RIM,REAR WHEEL (15M/CXMT4.00) | 1 шт. | — | |
|
| 3 | 65320-41F00 | SPOKE SET,REAR WHEEL | 1 шт. | — | |
|
| 4 | 09180-17092 | SPACER (17.5X25X113) | 1 шт. | — | |
|
| 5 | 09319-12019 | BUSH (12X41X34) | 6 шт. | — | |
|
| 6 | 08123-6303B | BEARING | 1 шт. | — | |
|
| 7 | 08143-6303B | BEARING,REAR HUB | 0 шт. | — | |
|
| 8 | 65200-41F01 | TUBE ASSY,WHEEL INNER | 1 шт. | — | |
|
| 9 | 65261-41F10 | PROTECTOR, WHEEL INNER TUBE | 1 шт. | — | |
|
| 10 | 64210-38A70-20H | PANEL,REAR BRAKE ANCHOR (SILV R) | 1 шт. | — | |
|
| 11 | 64400-38820 | SHOE SET,BRAKE | 1 шт. | — | |
|
| 12 | 55420-30000 | SPRING,BRAKE SHOE | 2 шт. | — | |
|
| 13 | 64441-38A20 | CAM,REAR BRAKE | 1 шт. | — | |
|
| 14 | 09280-15003 | O-RING (D:1.9,ID:14.5) | 1 шт. | — | |
|
| 15 | 09160-15048 | WASHER (15.5X24X1.6) | 1 шт. | — | |
|
| 16 | 64451-38A40 | LEVER, BRAKE CAM | 1 шт. | — | |
|
| 17 | 01570-06257 | BOLT | 1 шт. | — | |
|
| 18 | 64680-45113 | JOINT ASSY,REAR HUB DRIVEN | 1 шт. | — | |
|
| 19 | 09280-65003 | O-RING (D:2.1,ID:65) | 1 шт. | — | |
|
| 20 | 64677-45110 | WASHER, THRUST (T:1.6) | 3 шт. | — | |
|
| 21 | 09119-06049 | BOLT (6X16) | 6 шт. | — | |
|
| 22 | 09169-06030 | WASHER | 3 шт. | — | |
|
| 23 | 64711-19F00 | AXLE,REAR (L:302) | 1 шт. | — | |
|
| 24 | 09448-33006 | SPRING | 1 шт. | — | |
|
| 25 | 08319-2116A | NUT | 1 шт. | — | |
|
| 26 | 09160-17050 | WASHER (17X30X3.2) | 1 шт. | — | |
|
| 27 | 64741-41F00 | SPACER,REAR AXLE,R | 1 шт. | — | |
|
| 28 | 64772-34201 | SPACER,REAR AXLE,L | 1 шт. | — | |
|
| 29 | 65100-41F01 | TIRE (170/80-15M/C 77H) | 1 шт. | — | |
|
| 30 | 55411-26G00 | BALANCER WHEEL (15G) | 1 шт. | — | |
|
| 31 | 55413-41F00 | BALANCER WHEEL (30G) | 1 шт. | — | |
|
| 32 | 43300-41F00 | ROD ASSY,REAR BRAKE | 1 шт. | — | |
|
| 33 | 09209-13018 | .PIN (D:13.0,L:18.0) | 1 шт. | — | |
|
| 34 | 08322-0106B | WASHER | 2 шт. | — | |
|
| 35 | 04111-2015A | PIN | 1 шт. | — | |
|
| 36 | 09440-09004 | .SPRING | 1 шт. | — | |
|
| 37 | 09200-06013 | .PIN (10X16) | 1 шт. | — | |
|
| 38 | 09150-06010 | .NUT | 1 шт. | — | |
|
