| 1 | 44885-44AA0 | CUSHION (30X30X2) | 1 шт. | — | |
|
| 2 | 48411-06L00 | WINDSCREEN | 1 шт. | — | |
|
| 3 | 48416-06L00 | CUSHION,WINDSCREEN NO.3 | 3 шт. | — | |
|
| 4 | 09139-06206 | SCREW (6X20) | 4 шт. | — | |
|
| 5 | 09320-09016 | CUSHION (9X18X9.5) | 4 шт. | — | |
|
| 6 | 44294-43H11 | CUSHION,FUEL TANK COVER | 2 шт. | — | |
|
| 7 | 48412-06L00 | COVER,WINDSCREEN | 1 шт. | — | |
|
| 8 | 48413-06L00 | COVER,LOCK WINDSCREEN | 1 шт. | — | |
|
| 9 | 09409-06329 | CLIP | 4 шт. | — | |
|
| 10 | 47161-26J00 | CUSHION,FRAME COVER | 2 шт. | — | |
|
| 11 | 48421-06L00 | BRACE,WINDSCREEN RH | 1 шт. | — | |
|
| 12 | 48422-06L00 | SLIDER,WINDSCREEN FR RH | 1 шт. | — | |
|
| 13 | 48423-06L00 | SLIDER,WINDSCREEN REAR RH | 1 шт. | — | |
|
| 14 | 48431-06L00 | BRACE,WINDSCREEN LH | 1 шт. | — | |
|
| 15 | 48432-06L00 | SLIDER,WINDSCREEN FR LH | 1 шт. | — | |
|
| 16 | 48433-06L00 | SLIDER,WINDSCREEN REAR LH | 1 шт. | — | |
|
| 17 | 48441-06L00 | ROD,WINDSCREEN BRACE | 1 шт. | — | |
|
| 18 | 48442-06L00 | BOLT,WINDSCREEN BRACE ROD | 2 шт. | — | |
|
| 19 | 48451-06L00 | BRACKET,WINDSCREEN FRONT | 2 шт. | — | |
|
| 20 | 48452-06L00 | NUT,WINDSCREEN | 4 шт. | — | |
|
| 21 | 48454-06L00 | O-RING,WINDSCREEN | 4 шт. | — | |
|
| 22 | 48461-06L00 | BRACKET,WINDSCREEN REAR | 2 шт. | — | |
|
| 23 | 09106-08167 | BOLT (8X20) | 4 шт. | — | |
|
| 24 | 09409-06329 | CLIP | 2 шт. | — | |
|
| 25 | 48453-06L00 | NUT,WINDSCREEN | 1 шт. | — | |
|
| 26 | 48462-06L00 | STOPPER,LOCK SCREEN UPR NO.1 | 1 шт. | — | |
|
| 27 | 48463-06L00 | STOPPER,LOCK SCREEN UPR NO.2 | 1 шт. | — | |
|
| 28 | 48464-06L00 | STOPPER,LOCK SCREEN LWR | 1 шт. | — | |
|
| 29 | 48465-06L00 | SLIDER,LOCK SCREEN | 1 шт. | — | |
|
| 30 | 48466-06L00 | CUSHION,LOCK SCREEN | 1 шт. | — | |
|
| 31 | 48467-06L00 | SLINDER,LOCK SCREEN LWR | 1 шт. | — | |
|
| 32 | 48471-06L00 | BOLT,WINDSCREEN CTR | 1 шт. | — | |
|
| 33 | 48472-06L00 | LEVER,WINDSCREEN | 1 шт. | — | |
|
| 34 | 48473-06L00 | HINGE,WINDSCREEN LEVER | 1 шт. | — | |
|
| 35 | 48474-06L00 | SPRING,WINDSCREEN | 1 шт. | — | |
|
| 36 | 48475-06L00 | PLATE,WINDSCREEN | 2 шт. | — | |
|
| 37 | 09106-06090 | BOLT (6X25) | 1 шт. | — | |
|
| 38 | 09159-05045 | NUT | 2 шт. | — | |
|
| 39 | 02142-0520A | SCREW | 2 шт. | — | |
|
| 40 | 03541-0512A | SCREW | 2 шт. | — | |
|
| 41 | 08322-0105A | WASHER | 2 шт. | — | |
|
