| 1 | 41100-31J10-YAP | FRAME (BLACK) | 0 шт. | — | |
|
| 2 | 41200-31J20-YAP | RAIL, SEAT (BLACK) | 1 шт. | — | |
|
| 3 | 09139-10003 | BOLT (10X25) | 4 шт. | — | |
|
| 4 | 43580-31J00 | COVER,PIVOT RH | 1 шт. | — | |
|
| 8 | 43590-31J00 | COVER,PIVOT LH | 1 шт. | — | |
|
| 9 | 33652-38A10 | .CUSHION, PIVOT COVER NO.3 | 1 шт. | — | |
|
| 9 | 33652-38A10 | .CUSHION, PIVOT COVER NO.3 | 1 шт. | — | |
|
| 10 | 63115-37H00 | .CUSHION, PIVOT COVER NO.1 | 1 шт. | — | |
|
| 10 | 63115-37H00 | .CUSHION, PIVOT COVER NO.1 | 1 шт. | — | |
|
| 11 | 94429-21E00 | .CUSHION, PIVOT COVER NO.2 | 1 шт. | — | |
|
| 11 | 94429-21E00 | .CUSHION, PIVOT COVER NO.2 | 1 шт. | — | |
|
| 12 | 09139-05074 | BOLT (5X13) | 4 шт. | — | |
|
| 13 | 41922-19F20 | NUT,CRANK CASE ADJUST CTR | 1 шт. | — | |
|
| 14 | 41921-16G00 | BOLT, ADJUSTER LOWER | 1 шт. | — | |
|
| 15 | 41922-33E20 | NUT, ADJUSTER LOWER | 1 шт. | — | |
|
| 16 | 41941-19F01 | SPACER,MOUNTING REAR UPPER RH | 1 шт. | — | |
|
| 17 | 41921-47H00 | BOLT, CRANK CASE ADJUST | 1 шт. | — | |
|
| 18 | 41942-02F00 | SPACER, ENG HEAD MTG RR LH | 1 шт. | — | |
|
| 20 | 07130-0840B | BOLT | 1 шт. | — | |
|
| 20 | 07130-0840B | BOLT | 1 шт. | — | |
|
