| 1 | 17710-29F40 | RADIATOR WATER R | 1 шт. | — | |
|
| 2 | 09148-06015 | NUT | 1 шт. | — | |
|
| 3 | 17730-19D11 | CAP RADIATOR (1.1) | 1 шт. | — | |
|
| 4 | 17720-29F40 | RADIATOR WATER L | 1 шт. | — | |
|
| 5 | 09148-06015 | NUT | 1 шт. | — | |
|
| 6 | 17568-50F00 | UNION BOLT,AIR VENT | 1 шт. | — | |
|
| 7 | 09168-06026 | GASKET (6.4X11.5X0.84) | 1 шт. | — | |
|
| 8 | 17787-19A00 | CUSHION RADIATOR LWR | 4 шт. | — | |
|
| 9 | 09116-06147 | BOLT (6X25) | 4 шт. | — | |
|
| 10 | 09180-06243 | SPACER (6.5X10.5X14.1) | 4 шт. | — | |
|
| 11 | 17851-29F21 | HOSE,RADIATOR INLET | 1 шт. | — | |
|
| 12 | 17852-29F30 | HOSE RADIATOR OUTLET | 1 шт. | — | |
|
| 13 | 17853-29F10 | HOSE RADIATOR JOINT | 1 шт. | — | |
|
| 14 | 09402-28513 | CLAMP | 6 шт. | — | |
|
| 15 | 09402-32512 | CLAMP | 2 шт. | — | |
|
| 16 | 17733-03D10 | SCREW RADIATOR CAP | 1 шт. | — | |
|
| 17 | 34850-03D00 | SWITCH ASSY,WATER TEMP | 1 шт. | — | |
|
| 18 | 17680-24A30 | SWITCH FAN | 1 шт. | — | |
|
| 19 | 17911-29F11 | TANK RESERVOIR | 1 шт. | — | |
|
| 20 | 17913-29F00 | CUSHION RESERVOIR TANK | 1 шт. | — | |
|
| 21 | 17981-29F01 | HOSE RESERVOIR TANK INLET | 1 шт. | — | |
|
| 22 | 09352-50901-00B | HOSE (5X9X2000) | 1 шт. | — | |
|
| 23 | 09401-08411 | CLIP (ID:8.6) | 2 шт. | — | |
|
| 24 | 09404-08211 | CLAMP (L:45) | 1 шт. | — | |
|
| 25 | 09404-06429 | CLAMP (L:45) | 1 шт. | — | |
|
| 26 | 01550-0612A | BOLT | 1 шт. | — | |
|
| 27 | 09103-06274 | BOLT (6X16) | 2 шт. | — | |
|
| 28 | 09169-06053 | WASHER | 2 шт. | — | |
|
| 29 | 09103-06275 | BOLT (6X8) | 4 шт. | — | |
|
| 30 | 09160-06125 | WASHER (6.5X14X1.6) | 4 шт. | — | |
|
| 31 | 17831-37E11 | LOUVER RADIATOR | 2 шт. | — | |
|
| 32 | 17760-33K30-YUD | COVER,RADIATOR RH (GRAY) | 1 шт. | — | |
|
| 33 | 17760-33K30-019 | COVER,RADIATOR RH (BLACK) | 1 шт. | — | |
|
| 34 | 17760-33K30-30H | COVER,RADIATOR RH (WHITE) | 1 шт. | — | |
|
| 35 | 68685-29F30-B7Z | .TAPE,RADIATOR COVER RH (BLAC | 1 шт. | — | |
|
| 36 | 68685-29F30-B72 | .TAPE,RADIATOR COVER RH | 1 шт. | — | |
|
| 37 | 68685-29F30-B73 | .TAPE,RADIATOR COVER RH | 1 шт. | — | |
|
| 38 | 17770-33K30-YUD | COVER,RADIATOR LH (GRAY) | 1 шт. | — | |
|
| 39 | 17770-33K30-019 | COVER,RADIATOR LH (BLACK) | 1 шт. | — | |
|
| 40 | 17770-33K30-30H | COVER,RADIATOR LH (WHITE) | 1 шт. | — | |
|
| 41 | 68695-29F30-B7Z | .TAPE,RADIATOR COVER LH (BLAC | 0 шт. | — | |
|
| 42 | 68695-29F30-B72 | .TAPE,RADIATOR COVER LH | 1 шт. | — | |
|
| 43 | 68695-29F30-B73 | .TAPE,RADIATOR COVER LH | 1 шт. | — | |
|
| 44 | 17798-29E00 | CUSHION,RADIATOR COVER | 0 шт. | — | |
|
