| 1 | 47110-15H10-YAY | COVER, FRAME RH (BLACK) | 1 шт. | — | |
|
| 1 | 47110-15H10-YKZ | COVER, FRAME RH (BLUE) | 0 шт. | — | |
|
| 1 | 47110-15H10-YPA | COVER, FRAME RH (WHITE) | 0 шт. | — | |
|
| 2 | 68135-15H20-HUZ | TAPE, RH FOR YAY | 1 шт. | — | |
|
| 2 | 68135-15H20-JFF | TAPE, RH FOR YKZ | 0 шт. | — | |
|
| 2 | 68135-15H20-HWV | TAPE, RH FOR YPA | 1 шт. | — | |
|
| 4 | 47210-15H10-YAY | COVER, FRAME LH (BLACK) | 1 шт. | — | |
|
| 4 | 47210-15H10-YKZ | COVER, FRAME LH (BLUE) | 0 шт. | — | |
|
| 4 | 47210-15H10-YPA | COVER, FRAME LH (WHITE) | 1 шт. | — | |
|
| 5 | 68145-15H20-HUZ | TAPE, LH FOR YAY | 1 шт. | — | |
|
| 5 | 68145-15H20-JFF | TAPE, LH FOR YKZ | 0 шт. | — | |
|
| 5 | 68145-15H20-HWV | TAPE, LH FOR YPA | 1 шт. | — | |
|
| 6 | 47511-15H00 | CUSHION | 2 шт. | — | |
|
| 6 | 47511-15H00 | CUSHION | 2 шт. | — | |
|
| 7 | 09320-06016 | CUSHION | 4 шт. | — | |
|
| 8 | 09148-04034 | NUT | 2 шт. | — | |
|
| 9 | 47310-15H20-YAY | COVER, FRAME CENTER (BLACK) | 1 шт. | — | |
|
| 9 | 47310-15H20-YKZ | COVER, FRAME CENTER (BLUE) | 0 шт. | — | |
|
| 9 | 47310-15H20-YPA | COVER, FRAME CENTER (WHITE) | 1 шт. | — | |
|
| 10 | 68281-24F10-019 | EMBLEM (BLACK) FOR YPA | 2 шт. | — | |
|
| 10 | 68641-19F00-YD8 | EMBLEM (SILVER) FOR YAY,YKZ | 2 шт. | — | |
|
| 11 | 47312-15H00 | TAPE, CENTER | 2 шт. | — | |
|
| 12 | 45516-01H00 | CUSHION | 4 шт. | — | |
|
| 13 | 09136-05062 | SCREW (5X15) | 6 шт. | — | |
|
| 15 | 09139-06126 | SCREW (6X20) | 2 шт. | — | |
|
| 16 | 47411-15H00-YAY | LID, CENTER (BLACK) | 0 шт. | — | |
|
| 16 | 47411-15H00-YKZ | LID, CENTER (BLUE) | 0 шт. | — | |
|
| 16 | 47411-15H00-YPA | LID, CENTER (WHITE) | 0 шт. | — | |
|
| 17 | 09409-06314-5PK | CLIP | 4 шт. | — | |
|
| 18 | 09320-09016 | CUSHION (9X18X9.5) | 6 шт. | — | |
|
| 18 | 09320-09016 | CUSHION (9X18X9.5) | 2 шт. | — | |
|
| 19 | 09409-06329 | CLIP | 4 шт. | — | |
|
| 20 | 09136-06105 | SCREW (6X20) | 2 шт. | — | |
|
| 21 | 09180-06288 | SPACER (6.5X10X11) | 2 шт. | — | |
|
| 22 | 47115-16G00 | CUSHION, UPPER FRONT | 2 шт. | — | |
|
| 23 | 47191-24F00 | CUSHION, UPPER CENTER | 2 шт. | — | |
|
| 24 | 33651-37000 | PROTECTOR (170X95X3.0) | 2 шт. | — | |
|
| 25 | 47190-24F21 | WASHER,FRAME COVER | 2 шт. | — | |
|
| 26 | 47191-24F30 | CUSHION, UPPER REAR | 2 шт. | — | |
|
| 27 | 47191-24F20 | CUSHION,FRAME COVER CTR | 2 шт. | — | |
|
