| 1 | 51103-24F50 | DAMPER ASSY, FRONT FORK RH | 1 шт. | — | |
|
| 2 | 51110-24F50 | TUBE, INNER RH | 1 шт. | — | |
|
| 17 | 51104-24F50 | DAMPER ASSY, FRONT FORK LH | 0 шт. | — | |
|
| 18 | 51120-24F50 | TUBE, INNER LH | 1 шт. | — | |
|
| 19 | 51158-14200 | WASHER | 1 шт. | — | |
|
| 19 | 51158-14200 | WASHER | 1 шт. | — | |
|
| 20 | 51153-41G00 | SEAL, OIL | 1 шт. | — | |
|
| 20 | 51153-41G00 | SEAL, OIL | 1 шт. | — | |
|
| 21 | 51156-14200 | RING, STOPPER | 1 шт. | — | |
|
| 21 | 51156-14200 | RING, STOPPER | 1 шт. | — | |
|
| 22 | 51173-41G00 | SEAL, DUST | 1 шт. | — | |
|
| 22 | 51173-41G00 | SEAL, DUST | 1 шт. | — | |
|
| 23 | 51146-24F50 | CYLINDER | 0 шт. | — | |
|
| 23 | 51146-24F50 | CYLINDER | 0 шт. | — | |
|
| 24 | 51147-24F50 | BOLT | 1 шт. | — | |
|
| 24 | 51147-24F50 | BOLT | 1 шт. | — | |
|
| 25 | 51148-41310 | GASKET | 1 шт. | — | |
|
| 25 | 51148-41310 | GASKET | 1 шт. | — | |
|
| 26 | 51352-13A60 | NUT | 1 шт. | — | |
|
| 26 | 51352-13A60 | NUT | 1 шт. | — | |
|
| 27 | 51171-24F50 | SPRING, FRONT | 1 шт. | — | |
|
| 27 | 51171-24F50 | SPRING, FRONT | 1 шт. | — | |
|
| 28 | 51158-40F30 | GUIDE, SPRING | 1 шт. | — | |
|
| 28 | 51158-40F30 | GUIDE, SPRING | 1 шт. | — | |
|
| 29 | 51176-40F30 | .SPACER, SPRING | 1 шт. | — | |
|
| 29 | 51176-40F30 | .SPACER, SPRING | 1 шт. | — | |
|
| 30 | 51130-24F50 | TUBE, OUTER (BRONZE) | 1 шт. | — | |
|
| 30 | 51130-24F50 | TUBE, OUTER (BRONZE) | 1 шт. | — | |
|
| 31 | 51351-24F50 | CAP, FRONT FORK | 0 шт. | — | |
|
| 31 | 51351-24F50 | CAP, FRONT FORK | 0 шт. | — | |
|
| 32 | 62278-14100 | ..O RING | 1 шт. | — | |
|
| 32 | 62278-14100 | ..O RING | 1 шт. | — | |
|
| 33 | 51166-24F50 | BOLT | 4 шт. | — | |
|
