| 1 | 17662-48H00-000 | CONNECTOR, THERMOSTAT INLET | 0 шт. | — | |
|
| 2 | 17670-48H00-000 | THERMOSTAT, WATER | 0 шт. | — | |
|
| 3 | 01550-0616A-000 | BOLT | 0 шт. | — | |
|
| 4 | 17851-48H00-000 | HOSE, RADIATOR OUTLET | 0 шт. | — | |
|
| 5 | 17852-48H00-000 | HOSE, WATER PUMP INLET | 0 шт. | — | |
|
| 6 | 17853-48H00-000 | HOSE, WATER PUMP OUTLET | 0 шт. | — | |
|
| 7 | 17854-48H00-000 | HOSE, CYLINDER CONNECTOR | 0 шт. | — | |
|
| 8 | 17855-48H00-000 | HOSE, THERMOSTAT CONNECTOR | 0 шт. | — | |
|
| 9 | 17856-48H00-000 | HOSE, RADIATOR INLET | 0 шт. | — | |
|
| 10 | 17857-48H00-000 | HOSE, WATER BYPASS | 0 шт. | — | |
|
| 11 | 17861-48H00-000 | CONNECTOR, CYL WATER INLET | 0 шт. | — | |
|
| 12 | 17863-48H00-000 | O RING, CYL INLET CONNECTOR | 0 шт. | — | |
|
| 13 | 17870-48H00-000 | PIPE, WATER PUMP | 0 шт. | — | |
|
| 14 | 17880-48H00-000 | PIPE, CYLINDER HEAD OUTLET | 0 шт. | — | |
|
| 15 | 09160-06028-000 | WASHER (6.5X18X1) | 0 шт. | — | |
|
| 16 | 09180-06365-000 | SPACER (6.5X9X5) | 0 шт. | — | |
|
| 17 | 09280-18011-000 | O RING (D:3.2,ID:17.8) | 0 шт. | — | |
|
| 18 | 09320-08084-000 | CUSHION | 0 шт. | — | |
|
| 19 | 09401-12L02-000 | CLIP | 0 шт. | — | |
|
| 20 | 09402-27L01-000 | CLAMP | 0 шт. | — | |
|
| 21 | 09402-32L01-000 | CLAMP | 0 шт. | — | |
|
| 22 | 01547-0620A-000 | BOLT | 0 шт. | — | |
|
| 23 | 01550-0620A-000 | BOLT (6X20) | 0 шт. | — | |
|
| 24 | 07130-0612A-000 | BOLT | 0 шт. | — | |
|
| 25 | 17910-48H00-000 | TANK ASSY, RESERVOIR | 0 шт. | — | |
|
| 26 | 17932-12C00-000 | CAP, RESERVOIR TANK | 0 шт. | — | |
|
| 27 | 17920-48H00-000 | BRACKET, RESERVOIR TANK | 0 шт. | — | |
|
| 28 | 17981-19F00-000 | HOSE, RESERVOIR TANK INLET CUT AS REQUIRED | 0 шт. | — | |
|
| 29 | 17900-44810-000 | HOSE, RESERVOIR TANK OVER FLOW | 0 шт. | — | |
|
| 30 | 17985-48H00-000 | HOSE, FUEL TANK WATER DRAIN | 0 шт. | — | |
|
| 31 | 09111-06083-000 | BOLT (6X12) | 0 шт. | — | |
|
| 32 | 09367-08005-000 | 3 WAY | 0 шт. | — | |
|
| 33 | 09401-08L01-000 | CLIP | 0 шт. | — | |
|
| 34 | 29404-93J10-000 | CLAMP, RSVR TANK OVFL HOSE | 0 шт. | — | |
|
| 35 | 29404-93J10-000 | FUEL TANK WATER DRAIN HOSE | 0 шт. | — | |
|
| 36 | 07120-0612A-000 | BOLT | 0 шт. | — | |
|
| 37 | 17730-48H00-000 | CAP, RADIATOR 1.1 | 0 шт. | — | |
|
| 38 | 17791-48H00-000 | CONDUCTION, RADIATOR | 0 шт. | — | |
|
| 39 | 01550-0620A-000 | BOLT (6X20) | 0 шт. | — | |
|
| 40 | 13650-49X00-000 | SENSOR,TEMP | 0 шт. | — | |
|
| 41 | 13651-48H00-000 | GASKET, TEMP SENSOR | 0 шт. | — | |
|
