| 1 | 11341-48G00 | COVER,CLUTCH | 0 шт. | — | |
|
| 2 | 11482-48G00 | GASKET | 1 шт. | — | |
|
| 4 | 09103-06261 | BOLT (6X60) | 2 шт. | — | |
|
| 6 | 04211-09189 | PIN | 2 шт. | — | |
|
| 7 | 11351-48G00 | COVER,MAGNETO | 1 шт. | — | |
|
| 8 | 11352-48G00 | CAP | 1 шт. | — | |
|
| 9 | 11483-48G00 | .GASKET,MAGNETO COVER (5.8X13 | 1 шт. | — | |
|
| 10 | 09103-06213 | BOLT (6X30) | 7 шт. | — | |
|
| 10 | 09103-06213 | BOLT (6X30) | 13 шт. | — | |
|
| 11 | 09103-06238 | BOLT (6X50) | 3 шт. | — | |
|
| 12 | 09103-06225 | BOLT (6X70) | 3 шт. | — | |
|
| 13 | 09168-06023 | GASKET | 1 шт. | — | |
|
| 13 | 09168-06023 | GASKET | 3 шт. | — | |
|
| 14 | 04211-09149 | PIN | 2 шт. | — | |
|
| 15 | 09106-06068 | BOLT (6X10) MODEL K8/K9 | 3 шт. | — | |
|
| 15 | 07130-06127 | BOLT MODEL K6/K7 | 3 шт. | — | |
|
| 16 | 09106-06123 | BOLT (6X20) MODEL K8/K9 | 3 шт. | — | |
|
| 16 | 07130-06207 | BOLT MODEL K6/K7 | 3 шт. | — | |
|
| 17 | 09168-16002 | GASKET | 1 шт. | — | |
|
| 18 | 09248-16012-A05 | PLUG | 1 шт. | — | |
|
| 19 | 09259-30005 | PLUG, CRANKSHAFT HOLE | 1 шт. | — | |
|
| 20 | 09280-26006 | .O-RING (D:3.1,ID:26.4) | 1 шт. | — | |
|
| 21 | 11361-48G00 | COVER, SECONDARY DRIVE MODEL K6 | 1 шт. | — | |
|
| 21 | 11360-48G10 | COVER, SECONDARY DRIVE MODEL K7/K8/K9 | 1 шт. | — | |
|
| 22 | 11372-48G00 | BOLT MODEL K7/K8/K9 | 1 шт. | — | |
|
| 23 | 61135-95J00 | MOLDING MODEL K7/K8/K9 | 1 шт. | — | |
|
| 24 | 09139-06028 | BOLT | 3 шт. | — | |
|
| 25 | 09169-06062 | WASHER (6.3X17X1.6) | 3 шт. | — | |
|
| 26 | 09320-09501 | CUSHION | 3 шт. | — | |
|
| 27 | 68322-48G00 | NOTE, ENGINE OIL | 0 шт. | — | |
|
| 28 | 11353-48G00 | DAMPER, MAGNETO COVER CAP MODEL K8/K9 | 1 шт. | — | |
|
| 29 | 11363-48G00 | DAMPER, SEC DRIVE COVER MODEL K8/K9 | 0 шт. | — | |
|
| 30 | 11364-48G00 | DAMPER, SEC DRIVE COVER MODEL K8/K9 | 1 шт. | — | |
|
| 31 | 11365-48G00 | DAMPER, SEC DRIVE COVER MODEL K8/K9 | 0 шт. | — | |
|
