| 1 | 94631-04K00 | PANEL,METER RH | 1 шт. | — | |
|
| 2 | 94632-04K00 | PANEL,METER LH | 1 шт. | — | |
|
| 3 | 09139-05074 | BOLT (5X13) | 2 шт. | — | |
|
| 4 | 09148-05052 | NUT (M5) | 2 шт. | — | |
|
| 5 | 09409-06314 | CLIP (5.9X20.5) | 2 шт. | — | |
|
| 6 | 44572-37H00 | FASTENER, COWLING (20X15X0.8) | 2 шт. | — | |
|
| 7 | 94461-04K00 | COWLING,UNDER INNER RH | 1 шт. | — | |
|
| 8 | 94462-04K00 | COWLING,UNDER INNER LH | 1 шт. | — | |
|
| 9 | 94470-04KA0-YKV | COWLING,UNDER RH (BLACK) | 1 шт. | — | |
|
| 10 | 68181-04KA0-YES | .EMBLEM,"SUZUKI" (SILVER) | 1 шт. | — | |
|
| 11 | 94480-04KA0-YKV | COWLING,UNDER LH (BLACK) | 1 шт. | — | |
|
| 12 | 68181-04KA0-YES | .EMBLEM,"SUZUKI" (SILVER) | 1 шт. | — | |
|
| 13 | 94479-15H00 | CUSHION,UNDER COWLING,L | 4 шт. | — | |
|
| 14 | 94479-35F00 | CLIP | 1 шт. | — | |
|
| 15 | 94479-35F00 | CLIP | 2 шт. | — | |
|
| 16 | 94479-35F00 | CLIP | 2 шт. | — | |
|
| 17 | 94491-04K00 | COWLING,UNDER CTR | 1 шт. | — | |
|
| 18 | 94670-04K40-YWW | COVER,SIDE RH (WHITE) | 0 шт. | — | |
|
| 19 | 68685-04K30-BUL | .TAPE,SIDE COWLING RH (BLUE/B ACK/RED/WHITE) | 0 шт. | — | |
|
| 20 | 94680-04K40-YWW | COVER,SIDE LH (WHITE) | 0 шт. | — | |
|
| 21 | 68695-04K30-BUL | .TAPE,SIDE COWLING LH (BLUE/B ACK/RED/WHITE) | 0 шт. | — | |
|
| 22 | 09106-06117 | BOLT (6X12) | 4 шт. | — | |
|
| 23 | 09139-05064 | SCREW (5X13) | 2 шт. | — | |
|
| 24 | 09139-05074 | BOLT (5X13) | 2 шт. | — | |
|
| 25 | 09148-05052 | NUT (M5) | 2 шт. | — | |
|
| 26 | 09148-05052 | NUT (M5) | 2 шт. | — | |
|
| 27 | 09320-06504 | CUSHION (6X18X6) | 2 шт. | — | |
|
| 28 | 09321-06036 | CUSHION | 2 шт. | — | |
|
| 29 | 09321-06036 | CUSHION | 2 шт. | — | |
|
| 30 | 09329-18001 | CUSHION | 4 шт. | — | |
|
| 31 | 03541-0516B | SCREW | 8 шт. | — | |
|
| 32 | 03541-0516B | SCREW | 6 шт. | — | |
|
| 33 | 03541-0516B | SCREW | 1 шт. | — | |
|
| 34 | 94520-04K00 | BRACKET,UNDER COWL FR LH | 1 шт. | — | |
|
| 35 | 94530-04K00 | BRACKET,UNDER COWL RH | 1 шт. | — | |
|
| 36 | 94540-04K00 | BRACKET,UNDER COWL RR LH | 1 шт. | — | |
|
| 37 | 01550-0612A | BOLT | 2 шт. | — | |
|
| 38 | 68111-47HA0 | EMBLEM, S | 2 шт. | — | |
|
