| 1 | 49100-48G80-YWW | TANK ASSY, FUEL (WHITE) | 1 шт. | — | |
|
| 2 | 68111-48G60-YKY | .EMBLEM, "M109R" (BLEU) | 2 шт. | — | |
|
| 3 | 44191-48G10 | SHIELD,FUEL TANK HEAT | 1 шт. | — | |
|
| 4 | 44192-48G00 | TAPE,HEAT SHIELD | 2 шт. | — | |
|
| 5 | 44200-39860 | CAP SET | 1 шт. | — | |
|
| 6 | 34810-48G00 | GAUGE ASSY,FUEL LEVEL SENDER | 1 шт. | — | |
|
| 7 | 09329-10007 | CUSHION FRONT | 2 шт. | — | |
|
| 8 | 44541-13E10 | CUSHION, FUEL TANK | 2 шт. | — | |
|
| 9 | 09407-30402 | CLAMP (L:300) | 2 шт. | — | |
|
| 10 | 09404-06434 | CLAMP (L:80 T:1.0) SHIELD | 1 шт. | — | |
|
| 11 | 44530-48G10 | BRACKET,FUEL TANK REAR | 1 шт. | — | |
|
| 12 | 09116-06192 | BOLT (6X20) | 4 шт. | — | |
|
| 13 | 09320-08001 | CUSHION | 4 шт. | — | |
|
| 14 | 09169-06062 | WASHER (6.3X17X1.6) | 4 шт. | — | |
|
| 15 | 01550-0816A | BOLT REAR | 1 шт. | — | |
|
| 16 | SPECIAL NOTE | COLOR:KEL=YVB(BLACK)/YSF(BLUE) COLOR : | 0 шт. | — | |
|
| 17 | SPECIAL NOTE | COLOR:KEL=YVB(BLACK)/YSF(BLUE) AJP=YKY(BLUE),YWW(WHITE) | 0 шт. | — | |
|
