| 1 | 27100-48G20 | YOKE,UNIVERSAL JOINT | 1 шт. | — | |
|
| 2 | 27151-48G20 | SHAFT,PROPELLER (L:375) | 1 шт. | — | |
|
| 3 | 09283-30026 | OIL SEAL (30X40.5X5.5) | 1 шт. | — | |
|
| 4 | 09381-40003 | CIRCLIP | 1 шт. | — | |
|
| 5 | 09440-30008 | SPRING | 1 шт. | — | |
|
| 6 | 09159-10026 | .NUT | 3 шт. | — | |
|
| 7 | 09164-10008 | .WASHER (113X122X2.3) | 3 шт. | — | |
|
| 8 | 27300-48850-019 | GEAR & CASE SET | 1 шт. | — | |
|
| 9 | 27300-48850-019 | GEAR & CASE SET | 0 шт. | — | |
|
| 10 | 27172-24A00 | .COUPLING,FINAL DRIVE GEAR | 1 шт. | — | |
|
| 11 | 27311-24A03 | .GEAR,FINAL DRIVE BEVEL (NT:1 | 0 шт. | — | |
|
| 12 | 27311-24A03 | .GEAR,FINAL DRIVE BEVEL (NT:1 | 0 шт. | — | |
|
| 13 | 27312-24A02 | .STOPPER,FINAL DRIVE BEARING | 1 шт. | — | |
|
| 14 | 27313-38B00 | .PLATE,BEARING STOPPER | 1 шт. | — | |
|
| 15 | 27313-38B10 | .PLATE,BEARING STOPPER | 1 шт. | — | |
|
| 16 | 27445-24810 | .SHIM SET,FINAL DRIVE GEAR (T T:0.30/0.35/0.40/0.50/0.60 | 1 шт. | — | |
|
| 17 | 09108-10106 | .BOLT,STUD | 3 шт. | — | |
|
| 18 | 09159-16003 | NUT | 1 шт. | — | |
|
| 19 | 09160-16029 | WASHER (16X29X4.0) | 1 шт. | — | |
|
| 20 | 09160-54001 | WASHER (54X68X1.5) | 1 шт. | — | |
|
| 21 | 09262-28023 | .BEARING (28X68X18) | 1 шт. | — | |
|
| 22 | 09263-20062 | .BEARING (20X34X18) | 1 шт. | — | |
|
| 23 | 09280-64003 | O-RING (D:3.1,ID:63.9) | 1 шт. | — | |
|
| 24 | 09283-47002 | OIL SEAL (45.5X58X7) | 1 шт. | — | |
|
| 25 | 27320-48G00 | GEAR,FINAL DRIVEN BEVEL (NT:3 | 1 шт. | — | |
|
| 26 | 27326-48811 | SHIM SET,FINAL DRIVEN GEAR RH RH | 1 шт. | — | |
|
| 27 | 09181-40011 | .SHIM (40X46.8X0.95) | 0 шт. | — | |
|
| 28 | 09181-40013 | .SHIM (40X46.8X1.05) | 0 шт. | — | |
|
| 29 | 09181-40014 | .SHIM (40X46.8X1.1) | 0 шт. | — | |
|
| 30 | 09181-40176 | .SHIM (40X50X1.2) | 0 шт. | — | |
|
| 31 | 09181-40182 | .SHIM (40X50X1.4) | 0 шт. | — | |
|
| 32 | 09181-40212 | .SHIM (40X50X1.5) | 0 шт. | — | |
|
| 33 | 09262-85001 | BEARING (85X130X14) | 1 шт. | — | |
|
| 34 | 09263-40016 | BEARING (40X50X20) | 1 шт. | — | |
|
| 35 | 09283-38026 | OIL SEAL (38X46X6) | 1 шт. | — | |
|
| 36 | 09289-85001 | OIL SEAL (85X110X11) | 1 шт. | — | |
|
| 37 | 27450-48G70-019 | CASE,FINAL GEAR (BLACK) | 0 шт. | — | |
|
| 38 | 27461-38B00 | CASE,FINAL GEAR BEARING | 1 шт. | — | |
|
| 39 | 09168-14002 | .GASKET (13.8X18.8X4.8) | 1 шт. | — | |
|
| 40 | 09247-14002 | PLUG (MAGNETO) | 1 шт. | — | |
|
| 41 | 09259-30007 | PLUG (30X9) | 1 шт. | — | |
|
| 42 | 09280-26006 | .O-RING (D:3.1,ID:26.4) | 1 шт. | — | |
|
| 43 | 01550-0825A | BOLT | 8 шт. | — | |
|
| 44 | 01550-1025A | BOLT | 2 шт. | — | |
|
| 45 | 09248-16012 | PLUG (16X8) | 1 шт. | — | |
|
