| 1 | 44460-38B00 | HOSE, FUEL TANK JOINT MODEL K4/K5 | 0 шт. | — | |
|
| 1 | 44460-38B10 | HOSE, FUEL TANK JOINT MODEL K6/K7 | 0 шт. | — | |
|
| 1 | 44460-38BA0 | HOSE, FUEL TANK JOINT MODEL K8 | 0 шт. | — | |
|
| 3 | 09404-06433 | CLAMP | 1 шт. | — | — |
|
| 4 | 44240-38A00 | VALVE, FUEL TANK BREATHER | 1 шт. | — | |
|
| 5 | 44890-38B01 | BRACKET, BREATHER VALVE Includes Item(s) 6 | 0 шт. | — | |
|
| 7 | 01500-0510B | BOLT | 2 шт. | — | |
|
| 8 | 44892-24A00 | PLATE FUEL TANK BREATHER NO.2 Includes Item(s) 9 | 1 шт. | — | |
|
| 9 | 44894-24A00 | CUSHION (10X30X2) | 1 шт. | — | |
|
| 9 | 44894-24A00 | CUSHION (10X30X2) | 1 шт. | — | |
|
| 10 | 02142-0410B | SCREW | 0 шт. | — | |
|
| 11 | 44450-38B00 | HOSE, VALVE/CANISTER JOINT MODEL K4/K5/K6/K7 | 0 шт. | — | |
|
| 11 | 44450-38BA0 | HOSE, VALVE/CANISTER JOINT MODEL K8 | 0 шт. | — | |
|
| 12 | 09440-14026 | SPRING | 1 шт. | — | |
|
| 13 | 09401-11413 | CLIP | 2 шт. | — | |
|
| 13 | 09401-11413 | CLIP | 2 шт. | — | |
|
| 14 | 17210-38B00 | CANISTER MODEL K4/K5 | 0 шт. | — | |
|
| 14 | 17210-38B10 | CANISTER MODEL K6/K7/K8 | 0 шт. | — | |
|
| 15 | 44870-38B00 | PLATE, CANISTER FITTING | 0 шт. | — | |
|
| 16 | 01580-0816B | BOLT, PLATE | 0 шт. | — | |
|
| 17 | 01580-0616B | BOLT, CANISTER | 0 шт. | — | |
|
| 18 | 09160-06054 | WASHER | 3 шт. | — | |
|
| 19 | 09180-06038 | SPACER | 3 шт. | — | |
|
| 20 | 09320-08021 | CUSHION | 3 шт. | — | |
|
| 21 | 44991-38B01 | COVER, CANISTER | 2 шт. | — | |
|
| 21 | 44991-38B10 | COVER, CANISTER MODEL K6/K7/K8 | 0 шт. | — | |
|
| 22 | 09139-06078 | SCREW | 2 шт. | — | |
|
| 23 | 44445-38B00 | HOSE, CANISTER PIPE JOINT MODE K4/K5/K6/K7 | 1 шт. | — | |
|
| 23 | 44445-38BA0 | HOSE, CANISTER PIPE JOINT MODE K8 | 0 шт. | — | |
|
| 24 | 09440-14025 | SPRING | 0 шт. | — | |
|
| 26 | 44940-38B00 | PIPE, CANISTER | 0 шт. | — | |
|
| 27 | 44440-38B00 | HOSE, PIPE JOINT MODE K4/K5/K6/K7 | 0 шт. | — | |
|
| 27 | 44440-38BA0 | HOSE, PIPE JOINT MODEL K8 | 0 шт. | — | |
|
| 28 | 09401-11415 | CLIP | 2 шт. | — | |
|
| 28 | 09401-11415 | CLIP | 2 шт. | — | |
|
| 29 | 09367-06004 | SEPARATOR, VALVE | 0 шт. | — | |
|
| 30 | 09401-08401 | CLIP | 2 шт. | — | |
|
