| 1 | 17661-48G10 | COVER, THERMOSTAT | 1 шт. | — | |
|
| 2 | 17662-40H00 | CONNECTOR, THERMOSTAT INLET | 0 шт. | — | |
|
| 3 | 17670-06G50 | THERMOSTAT, WATER | 1 шт. | — | |
|
| 4 | 09280-18008 | O RING (D:3.2,ID:17.8) | 1 шт. | — | |
|
| 5 | 01547-0620A | BOLT | 2 шт. | — | |
|
| 6 | 01547-0625A | BOLT | 1 шт. | — | |
|
| 7 | 17851-40H10 | HOSE, RADIATOR INLET | 1 шт. | — | |
|
| 8 | 17852-40H10 | HOSE, RADIATOR OUTLET | 1 шт. | — | |
|
| 9 | 17853-40H00 | HOSE, CYLINDER INLET | 0 шт. | — | |
|
| 10 | 17854-40H00 | HOSE, WATER BYPASS UPPER | 0 шт. | — | |
|
| 11 | 17855-40H00 | HOSE, WATER BYPASS LOWER | 0 шт. | — | |
|
| 12 | 17856-40H00 | HOSE, RR CYLINDER HEAD OUTLET | 1 шт. | — | |
|
| 13 | 17857-40H10 | HOSE, THERMOSTAT OUTLET | 1 шт. | — | |
|
| 14 | 17858-40H00 | HOSE, CONDUCTION | 1 шт. | — | |
|
| 15 | 17860-40H00 | PIPE, CYLINDER WATER INLET | 0 шт. | — | |
|
| 16 | 17890-06G20 | UNION,CONNECTOR HOSE | 1 шт. | — | |
|
| 17 | 17910-40H00 | TANK ASSY, RESERVOIR | 0 шт. | — | |
|
| 18 | 17931-02FA0 | .CAP, RESERVOIR TANK | 1 шт. | — | |
|
| 19 | 17982-40H00 | HOSE, TANK OVERFLOW | 0 шт. | — | |
|
| 20 | 17981-40H00 | HOSE, TANK INLET NO.1 | 0 шт. | — | |
|
| 21 | 09352-50901-600 | HOSE (5X9X600) L:600->500 | 1 шт. | — | |
|
| 22 | 09364-06005 | UNION | 1 шт. | — | |
|
| 23 | 09111-06085 | BOLT (6X12) | 1 шт. | — | |
|
| 24 | 09401-08411 | CLIP | 3 шт. | — | |
|
| 25 | 09401-10411 | CLIP | 1 шт. | — | |
|
| 26 | 09407-14403 | CLAMP (L:125) | 1 шт. | — | |
|
| 27 | 09407-19401 | CLAMP (L:190) | 2 шт. | — | |
|
| 28 | 17730-14G00 | CAP, RADIATOR (1.1) | 1 шт. | — | |
|
| 29 | 17791-14G00 | CONDUCTION, RADIATOR | 1 шт. | — | |
|
| 30 | 01547-0512A | BOLT | 1 шт. | — | |
|
| 31 | 17792-40H00 | BRACKET, CONDUCTION | 0 шт. | — | |
|
| 32 | 01547-0612A | BOLT | 1 шт. | — | |
|
| 33 | 13650-49X00 | SENSOR,TEMP | 1 шт. | — | |
|
| 34 | 09168-12017 | GASKET (12X17X1) | 1 шт. | — | |
|
| 35 | 17891-48G00 | JOINT, 3 WAY | 1 шт. | — | |
|
| 36 | 09103-06274 | BOLT (6X16) | 2 шт. | — | |
|
| 37 | 07130-0612A | BOLT | 1 шт. | — | |
|
| 38 | 09280-18008 | O RING (D:3.2,ID:17.8) | 1 шт. | — | |
|
| 39 | 09280-26005 | O RING (D:2.4,ID:26.2) | 1 шт. | — | |
|
| 40 | 09401-12414 | CLAMP | 4 шт. | — | |
|
| 41 | 09402-32512 | CLAMP | 4 шт. | — | |
|
| 42 | 09402-38512 | CLAMP | 3 шт. | — | |
|
| 43 | 09402-35501 | CLAMP | 5 шт. | — | |
|
| 44 | 63131-10F00 | TAPE,RR FENDER (30X75X0.2) | 1 шт. | — | |
|
| 45 | 17912-06J00 | CUSHION, RESERVOIR TANK HOSE | 0 шт. | — | |
|
