| 1 | 12710-17K00 | CAMSHAFT,INTAKE | 1 шт. | — | |
|
| 2 | 12740-17K00 | .SPROCKET,CAMSHAFT INTAKE (NT 34) | 1 шт. | — | |
|
| 3 | 12746-17K00 | .BOLT,SPROCKET INTAKE | 1 шт. | — | |
|
| 4 | 09261-03020 | .PIN (3X8) | 1 шт. | — | |
|
| 5 | 12720-17K00 | CAMSHAFT,EXHAUST | 1 шт. | — | |
|
| 6 | 12751-17K00 | .SPROCKET,CAMSHAFT EXHAUST (N :34) | 1 шт. | — | |
|
| 7 | 09103-07003 | .BOLT (7X10) | 2 шт. | — | |
|
| 8 | 12841-17K01 | ARM,VALVE ROCKER | 16 шт. | — | |
|
| 9 | 12861-17K00 | SHAFT,VALVE ROCKER ARM | 8 шт. | — | |
|
| 10 | 09261-04005 | ROLLER (4X23.8) | 1 шт. | — | |
|
| 11 | 12872-17K00 | PIN,ROCKER ARM SHAFT EXHAUST | 1 шт. | — | |
|
| 12 | 12911-17K00 | VALVE,INTAKE | 8 шт. | — | |
|
| 13 | 12912-17K00 | VALVE,EXHAUST | 8 шт. | — | |
|
| 14 | 12919-17K00 | OIL SEAL,VALVE STEM | 16 шт. | — | |
|
| 15 | 12920-17K10 | SPRING SET,VALVE | 16 шт. | — | |
|
| 16 | 12931-17K01 | RETAINER,VALVE SPRING | 16 шт. | — | |
|
| 17 | 12932-32C00 | COTTER,VALVE | 32 шт. | — | |
|
| 18 | 12933-47H00 | SEAT,VALVE SPRING | 16 шт. | — | |
|
| 19 | 12892-05C00-170 | SHIM,TAPPET (T:1.70) | 16 шт. | — | |
|
| 20 | 12892-05C00-175 | SHIM,TAPPET (T:1.75) | 16 шт. | — | |
|
| 21 | 12892-05C00-180 | SHIM,TAPPET (T:1.80) | 16 шт. | — | |
|
| 22 | 12892-05C00-185 | SHIM,TAPPET (T:1.85) | 16 шт. | — | |
|
| 23 | 12892-05C00-190 | SHIM,TAPPET (T:1.90) | 16 шт. | — | |
|
| 24 | 12892-05C00-195 | SHIM,TAPPET (T:1.95) | 16 шт. | — | |
|
| 25 | 12892-05C00-200 | SHIM,TAPPET (T:2.00) | 16 шт. | — | |
|
| 26 | 12892-05C00-205 | SHIM,TAPPET (T:2.05) | 16 шт. | — | |
|
| 27 | 12892-05C00-210 | SHIM,TAPPET (T:2.10) | 16 шт. | — | |
|
| 28 | 12892-05C00-215 | SHIM,TAPPET (T:2.15) | 16 шт. | — | |
|
| 29 | 12892-05C00-220 | SHIM,TAPPET (T:2.20) | 16 шт. | — | |
|
| 30 | 12892-05C00-225 | SHIM,TAPPET (T:2.25) | 16 шт. | — | |
|
| 31 | 12892-05C00-230 | SHIM,TAPPET (T:2.30) | 16 шт. | — | |
|
| 32 | 12892-05C00-235 | SHIM,TAPPET (T:2.35) | 16 шт. | — | |
|
| 33 | 12892-05C00-240 | SHIM,TAPPET (T:2.40) | 16 шт. | — | |
|
| 34 | 12892-05C00-245 | SHIM,TAPPET (T:2.45) | 16 шт. | — | |
|
| 35 | 12892-05C00-250 | SHIM,TAPPET (T:2.50) | 0 шт. | — | |
|
| 36 | 12892-05C00-255 | SHIM,TAPPET (T:2.55) | 16 шт. | — | |
|
| 37 | 12892-05C00-260 | SHIM,TAPPET (T:2.60) | 0 шт. | — | |
|
| 38 | 12892-05C00-265 | SHIM,TAPPET (T:2.65) | 0 шт. | — | |
|
| 39 | 12892-05C00-270 | SHIM,TAPPET (T:2.70) | 0 шт. | — | |
|
| 40 | 12800-05830 | SHIM SET,TAPPET (5PCS.EACH) OPT,NOT ILLUSTRATED | 1 шт. | — | |
|
| 41 | 99000-69491 | .CASE,TAPPET SHIM OPT,NOT ILLUSTRATED | 1 шт. | — | |
|
