| 1 | 94410-17K30-YWW | COWLING,BODY (WHITE) BODY COLOR:AGT | 1 шт. | — | |
|
| 2 | 94410-17K30-YKV | COWLING,BODY (BLACK) BODY COLOR:KGL | 1 шт. | — | |
|
| 3 | 44192-44H00 | .CUSHION,FUEL TANK (L:160) | 1 шт. | — | |
|
| 4 | 44572-02F01 | FASTENER (25X33X2.6) | 1 шт. | — | |
|
| 5 | 44572-37H00 | FASTENER, COWLING (20X15X0.8) | 2 шт. | — | |
|
| 6 | 94443-21H00 | .TAPE,FR TURNSIGNAL (5X20X0.4 .4) | 2 шт. | — | |
|
| 7 | 68177-04A00-BV7 | .EMBLEM,SUZUKI (RED,WHITE) BODY COLOR:AGT | 0 шт. | — | |
|
| 8 | 68177-04A00-BFK | .EMBLEM,SUZUKI (RED,BLACK) BODY COLOR:KGL | 0 шт. | — | |
|
| 9 | 94611-17K00 | WINDSCREEN | 1 шт. | — | |
|
| 10 | 94631-17K00 | SCREW,WINDSCREEN FRONT | 4 шт. | — | |
|
| 11 | 94621-17K00 | SCREW,WINDSCREEN REAR | 2 шт. | — | |
|
| 12 | 09159-05019 | NUT (M5) | 6 шт. | — | |
|
| 13 | 94511-17K00 | BRACE,COWLING | 1 шт. | — | |
|
| 14 | 09103-08207 | BOLT (8X45) | 2 шт. | — | |
|
| 15 | 08313-2008A | NUT | 2 шт. | — | |
|
| 16 | 09320-08028 | CUSHION (8X26X7) | 2 шт. | — | |
|
| 17 | 94630-17K00 | PANEL,METER,R | 1 шт. | — | |
|
| 18 | 33652-20C00 | PROTECTOR (50X50X5) CUT AS REQUIRED | 1 шт. | — | |
|
| 19 | 44279-18K00 | CUSHION (5X50X5) (5X50X5) | 1 шт. | — | |
|
| 20 | 73415-70A00 | .PAD | 1 шт. | — | |
|
| 21 | 94640-17K00 | PANEL,METER,L | 1 шт. | — | |
|
| 22 | 33652-20C00 | PROTECTOR (50X50X5) CUT AS REQUIRED | 1 шт. | — | |
|
| 23 | 44279-18K00 | CUSHION (5X50X5) (5X50X5) | 1 шт. | — | |
|
| 24 | 73415-70A00 | .PAD | 1 шт. | — | |
|
