| 1 | 12160-17K00 | CONNROD ASSY | 4 шт. | — | |
|
| 2 | 12163-17K00 | .BOLT,CONNROD | 8 шт. | — | |
|
| 3 | 04221-03059 | .PIN | 8 шт. | — | |
|
| 4 | 12164-17K00-0A0 | BEARING,CRANK PIN UPPER GREEN | 4 шт. | — | |
|
| 5 | 12164-17K00-0B0 | BEARING,CRANK PIN UPPER BLACK | 4 шт. | — | |
|
| 6 | 12164-17K00-0C0 | BEARING,CRANK PIN UPPER BROWN | 4 шт. | — | |
|
| 7 | 12164-17K00-0D0 | BEARING,CRANK PIN UPPER YELLOW | 4 шт. | — | |
|
| 8 | 12164-17K10-0A0 | BEARING,CRANK PIN LOWER | 4 шт. | — | |
|
| 9 | 12164-17K10-0B0 | BEARING,CRANK PIN LOWER | 4 шт. | — | |
|
| 10 | 12164-17K10-0C0 | BEARING,CRANK PIN LOWER | 4 шт. | — | |
|
| 11 | 12164-17K10-0D0 | BEARING,CRANK PIN LOWER | 4 шт. | — | |
|
| 12 | 12000-17870 | CRANKSHAFT SET | 1 шт. | — | |
|
| 13 | 12228-48B00-0B0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 14 | 12228-48B00-0C0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 15 | 12228-48B00-0D0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 16 | 12228-48B00-0E0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 17 | 12228-48B00-0F0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 18 | 12228-48B00-0G0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 19 | 12228-48B00-0H0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 20 | 12228-48B00-0E0 | .BEARING,CRANK THRUST | 1 шт. | — | |
|
| 21 | 12229-17K00-0A0 | BEARING,CRANKSHAFT | 4 шт. | — | |
|
| 22 | 12229-17K00-0B0 | BEARING,CRANKSHAFT | 4 шт. | — | |
|
| 23 | 12229-17K00-0C0 | BEARING,CRANKSHAFT | 4 шт. | — | |
|
| 24 | 12229-17K00-0D0 | BEARING,CRANKSHAFT | 4 шт. | — | |
|
| 25 | 12229-17K00-0E0 | BEARING,CRANKSHAFT | 4 шт. | — | |
|
| 26 | 12229-17K10-0A0 | BEARING,CRANKSHAFT | 6 шт. | — | |
|
| 27 | 12229-17K10-0B0 | BEARING,CRANKSHAFT | 6 шт. | — | |
|
| 28 | 12229-17K10-0C0 | BEARING,CRANKSHAFT | 6 шт. | — | |
|
| 29 | 12229-17K10-0D0 | BEARING,CRANKSHAFT | 6 шт. | — | |
|
| 30 | 12229-17K10-0E0 | BEARING,CRANKSHAFT | 6 шт. | — | |
|
| 31 | 12111-17K00-0F0 | PISTON | 4 шт. | — | |
|
| 32 | 12140-17K00 | RING SET,PISTON | 4 шт. | — | |
|
| 33 | 12151-17K00 | PIN,PISTON | 4 шт. | — | |
|
| 34 | 12152-17K01 | CIRCLIP,PISTON PIN | 8 шт. | — | |
|
| 35 | 12731-47H00 | SPROCKET,CAM CHAIN DRIVE (NT: 7) | 1 шт. | — | |
|
