| 1 | 43511-17K00 | BRACKET,FR FOOTREST,R | 1 шт. | — | |
|
| 2 | 43521-17K00 | BRACKET,FR FOOTREST,L | 1 шт. | — | |
|
| 3 | 43516-37H10 | BAR,FRONT FOOTREST,R | 1 шт. | — | |
|
| 4 | 43526-37H10 | BAR,FRONT FOOTREST,L | 1 шт. | — | |
|
| 5 | 43531-41G20 | HOLDER,FOOTREST | 1 шт. | — | |
|
| 6 | 43571-17K00 | GUARD,FR FOOTREST,R | 1 шт. | — | |
|
| 7 | 43576-17K00 | GUARD,FR FOOTREST,L | 1 шт. | — | |
|
| 8 | 43576-48B40 | BOLT,BANK SENSOR | 2 шт. | — | |
|
| 9 | 43577-35F20 | SCREW,FOOTREST GUARD,L | 2 шт. | — | |
|
| 10 | 43581-47H00 | SPRING,FRONT FOOTREST | 2 шт. | — | |
|
| 11 | 09106-08200 | BOLT (8X23) | 4 шт. | — | |
|
| 12 | 09106-10064 | BOLT (10X28) | 1 шт. | — | |
|
| 13 | 09208-08018 | PIN | 2 шт. | — | |
|
| 14 | 08332-1106A | E-RING | 2 шт. | — | |
|
| 15 | 43600-17K00 | FOOTREST ASSY,PILLION,R | 1 шт. | — | |
|
| 16 | 43611-37H30 | .BAR,PILLION FOOTREST,R | 1 шт. | — | |
|
| 17 | 43811-17K00 | .BRACKET,PILLION FOOTREST,R | 1 шт. | — | |
|
| 18 | 09208-08020 | .PIN | 1 шт. | — | |
|
| 19 | 09440-05005 | SPRING | 1 шт. | — | |
|
| 20 | 06111-07004 | BALL | 1 шт. | — | |
|
| 21 | 08332-1106A | E-RING | 1 шт. | — | |
|
| 22 | 43816-01H20 | PLATE,PILLION FOOTREST | 1 шт. | — | |
|
| 23 | 43700-17K00 | FOOTREST ASSY,PILLION,L | 1 шт. | — | |
|
| 24 | 43621-37H30 | .BAR,PILLION FOOTREST,L | 1 шт. | — | |
|
| 25 | 43821-17K00 | .BRACKET,PILLION FOOTREST,L | 1 шт. | — | |
|
| 26 | 09208-08020 | .PIN | 1 шт. | — | |
|
| 27 | 09440-05005 | SPRING | 1 шт. | — | |
|
| 28 | 06111-07004 | BALL | 1 шт. | — | |
|
| 29 | 08332-1106A | E-RING | 1 шт. | — | |
|
| 30 | 43816-01H20 | PLATE,PILLION FOOTREST | 1 шт. | — | |
|
| 31 | 09106-08200 | BOLT (8X23) | 4 шт. | — | |
|
