| 1 | 25211-38A02 | FORK, GEAR SHIFTING NO.1 MODEL K6/K7/K8 | 2 шт. | — | |
|
| 2 | 25211-38A10 | FORK, GEAR SHIFTING NO.1 MODEL K9 | 0 шт. | — | |
|
| 3 | 25221-38A01 | FORK, GEAR SHIFTING NO.2 MODEL K6/K7/K8 | 0 шт. | — | |
|
| 4 | 25221-38A10 | FORK, GEAR SHIFTING NO.2 MODEL K9 | 2 шт. | — | |
|
| 5 | 25411-38A00 | SHAFT, GEAR SHIFT FORK (L:115 | 2 шт. | — | |
|
| 6 | 25310-41F00 | CAM, GEAR SHIFTING Includes Item(s) 5 | 1 шт. | — | |
|
| 7 | 04221-04089 | .PIN | 2 шт. | — | |
|
| 8 | 25322-31310 | GEAR, GEAR SHIFT CAM DRIVEN | 1 шт. | — | |
|
| 9 | 25323-34201 | PAWL, GEAR SHIFT NO.1 | 1 шт. | — | |
|
| 10 | 25324-34201 | PAWL, GEAR SHIFT NO.2 | 1 шт. | — | |
|
| 11 | 09261-05003 | PIN | 2 шт. | — | |
|
| 12 | 09440-04003 | SPRING | 2 шт. | — | |
|
| 13 | 25331-38A00 | LIFTER, PAWL | 1 шт. | — | |
|
| 14 | 25341-38A00 | GUIDE, CAM | 0 шт. | — | |
|
| 15 | 09126-06011 | SCREW (6X12) | 2 шт. | — | |
|
| 16 | 09160-25059 | WASHER (25X32X3) | 1 шт. | — | |
|
| 17 | 25332-38A10 | BOSS, SHIFT PAWL LIFTER | 0 шт. | — | |
|
| 18 | 08316-1006B | NUT | 2 шт. | — | |
|
| 19 | 09262-25006 | BEARING (25X47X8) | 1 шт. | — | |
|
| 20 | 24741-21A00 | RETAINER, BEARING | 2 шт. | — | |
|
| 21 | 09125-06110 | SCREW (6X12) | 2 шт. | — | |
|
| 22 | 25350-38A00 | STOPPER, CAM | 0 шт. | — | |
|
| 23 | 09443-09027 | SPRING | 1 шт. | — | |
|
| 24 | 25355-38A10 | SUPPORT, CAM STOPPER | 0 шт. | — | |
|
| 25 | 08211-06141 | WASHER | 1 шт. | — | |
|
| 26 | 25380-38A02 | PLATE, STOPPER | 0 шт. | — | |
|
| 27 | 25312-38A00 | PIN, SHIFT CAM | 1 шт. | — | |
|
| 28 | 09223-04004 | .RIVET (L:11.0) | 0 шт. | — | |
|
| 29 | 25510-38A00 | SHAFT, GEAR SHIFTING | 1 шт. | — | |
|
| 30 | 09180-12068 | SPACER (12X20X15.3) | 1 шт. | — | |
|
| 31 | 09444-26013 | SPRING | 1 шт. | — | |
|
| 32 | 25671-01011 | STOPPER,GEAR SHIFT ARM | 1 шт. | — | |
|
| 33 | 09285-12002 | OIL SEAL (12X22X9) | 1 шт. | — | |
|
| 34 | 25520-38B00 | ARM, GEAR SHIFT LINK Includes Item(s) 33 | 1 шт. | — | |
|
| 35 | 25526-47000 | COVER, DUST | 1 шт. | — | |
|
| 36 | 01547-0620A | BOLT, GEAR ARM | 1 шт. | — | |
|
| 37 | 25525-41F00 | ROD, GEAR SHIFT LINK | 1 шт. | — | |
|
| 38 | 09140-06011 | NUT, GEAR SHIFT | 1 шт. | — | |
|
| 39 | 08310-00067 | .NUT | 1 шт. | — | |
|
| 40 | 25600-41F10 | LEVER ASSY, GEAR SHIFT MODEL K6/K7/K8 | 1 шт. | — | |
|
| 41 | 25600-41F20 | LEVER ASSY, GEAR SHIFT MODEL K9; Includes Item(s) 39 - 41 | 1 шт. | — | |
|
| 42 | 25526-47000 | COVER, DUST | 1 шт. | — | |
|
| 43 | 25652-10F00 | RUBBER, GEAR FR | 1 шт. | — | |
|
| 44 | 43151-01400 | RUBBER, GEAR RR | 1 шт. | — | |
|
| 45 | 25617-10F00 | SPACER, GEAR SHIFT | 1 шт. | — | |
|
| 46 | 09103-10300 | BOLT, GEAR SHIFT | 1 шт. | — | |
|
| 47 | 09160-10127 | WASHER (14.2X22X1) MODEL K6/K7/K8 | 1 шт. | — | |
|
| 48 | 09164-18009 | WASHER, GEAR SHIFT MODEL K9 | 1 шт. | — | |
|
| 49 | 08310-0010B | NUT, GEAR SHIFT | 1 шт. | — | |
|
| 50 | 31497-45000 | CLAMP,MAGNETO LEAD | 1 шт. | — | |
|
| 51 | 37730-41F01 | BASE ASSY, GEAR SHIFT TERM Includes Item(s) 48 | 1 шт. | — | |
|
| 52 | 36618-43410 | CAP, OIL PRESSURE | 1 шт. | — | |
|
| 53 | 09280-26005 | O RING (D:2.4,ID:26.2) | 1 шт. | — | |
|
| 54 | 07120-0516A | BOLT | 2 шт. | — | |
|
| 55 | 09209-05011 | CONTACT, SWITCH | 2 шт. | — | |
|
| 56 | 09440-04010 | SPRING | 2 шт. | — | |
|
| 57 | 09404-06429 | CLAMP (L:45) | 1 шт. | — | |
|
